Blue Smart IP65 Charger 24/5(1) 230V CEE 7/16 Retail
In stock
$ 131
In stock
The Blue Smart IP65 Charger is the new professional battery charger with built-in Bluetooth. The Blue Smart IP65 Charger can be used on devices in your workshop and on motor vehicles, such as (classic) cars; motorbikes; boats and camper-vans.
New: IP65 6V/12V 1.1A
New: IP65 12/5 replaced by smaller equivalent model: IP65s 12/5
Additional information
| Weight | 0,93 kg |
|---|---|
| Dimensions | 22 × 30 × 8 cm |
| batteryVoltageNominal | 24 V |
| chargeCurrentNormal | 5 A |
| chargeCurrentLow | 2 A |
| aCInputVoltageRange | [180, 265] VAC |
| acInputFrequencyRange | [45, 65] Hz |
| efficiency | 95 % |
| standbyPowerConsumption | 0.5 W |
| chargeVoltageAbsorption | Normal: 28.8V High: 29.4V Lithium: 28.4V |
| chargeVoltageFloat | Normal: 27.6V High: 27.6V Li-ion: 27.0V |
| chargeVoltageStorage | Normal: 26.4V High: 26.4V Li-ion: 27.0V |
| chargeAlgorithm | Adaptive, 7-stage |
| lithiumCompatible | 1 |
| backCurrentDrain | 1 mA |
| backCurrentDrainMonth | 0.7 Ah/mo |
| powerSupplyMode | 1 |
| Programable | 1 |
| protections | Battery reverse polarity, Output short-circuit, Over temperature |
| maxHumidity | 95 % |
| acConnectionTerminalType | Cable of 1.5 meter with CEE 7/16 plug |
| batteryConnectionTerminalType | Red and black 1.5 meter cable with plugable M8 eyelets or clamps |
| protectionCategory | IP65 |
| weight | 0.9 kg |
| height | 47 mm |
| width | 95 mm |
| depth | 182 mm |
| safety | EN-IEC 60335-1, EN-IEC 60335-2-29 |
| emission | EN 55014-1, EN-IEC 61000-3-2, EN-IEC 61000-6-3 |
| immunity | EN 55014-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2 |
