EasySolar-II 48/5000/70-50 MPPT 250/100 GX
In stock
$ 2.202
In stock
The EasySolar-II GX combines an MPPT Solar Charge Controller, an inverter/charger and control hub in one enclosure. The product is easy to install, with a minimum of wiring.
Additional information
| Weight | 38,8 kg |
|---|---|
| Dimensions | 41 × 66 × 35 cm |
| batteryVoltageNominal | 48 V |
| powerControl | 1 |
| powerAssist | 1 |
| transferSwitchCurrentRating | 50 A |
| maxAcInputCurrent | 50 A |
| auxAcCurrent | 50 A |
| dCInputVoltageRange | [38, 66] VDC |
| aCOutputVoltage | 230 VAC |
| aCOutputFrequency | 50 Hz |
| contPowerVA25 | 5, 000 VA |
| contPowerW25 | 4, 000 W |
| contPowerW40 | 3, 700 W |
| contPowerW55 | 3, 000 W |
| peakPowerRating | 9, 000 W |
| maxAppFeedinPower | 5, 000 VA |
| maxEfficiency | 96 % |
| zeroLoadPower | 18 W |
| zeroLoadPowerAES | 12 W |
| zeroLoadPowerSearch | 2 W |
| aCInputVoltageRange | [187, 265] VAC |
| aCInputFrequencyRange | [45, 65] Hz |
| chargeVoltageAbsorption | 57.6 VDC |
| chargeVoltageFloat | 55.2 VDC |
| chargeVoltageStorage | 52.8 VDC |
| chargeAlgorithm | Adaptive, 4-stage |
| maximumBatteryChargeCurrent | 70 A |
| temperatureSensor | Included |
| SolarChargerModel | MPPT 250/100-Tr |
| maxOutputCurrentSolar | 100 A |
| maxPvPower | 5, 800 W |
| maxPvOpenCircuitVoltage | 250 V |
| maxiEfficiencySolarCharger | 99 % |
| selfConsumption | 20 mA |
| chargeVoltageAbsorption1 | 57.6 VDC |
| chargeVoltageFloat1 | 55.2 VDC |
| chargeAlgorithm1 | Adaptive, 4-stage |
| externalAcCurrentSensor | 50A or 100A (optional) |
| programmableRelay | AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC |
| protections | Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple |
| communicationPort | VE.Direct, VE.Bus, VE.Can, BMS-Can, WiFi, Ethernet |
| remoteTerminal | On / Off |
| computerProgramming | 1 |
| fanAssistCooling | 1 |
| maxHumidity | 95 % |
| batteryConnectionTerminalType | M8 bolts |
| pVConnectionTerminalType | M6 bolts |
| remoteTerminalType | Screw terminal two pole |
| relayTerminal | Screw terminal 3-pole |
| vebusTerminalType | Two RJ45 terminals |
| material | Steel |
| colour | Blue (RAL 5012) |
| protectionCategory | IP21 |
| weight | 38.6 kg |
| height | 604 mm |
| width | 323 mm |
| depth | 253 mm |
| safety | EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2 |
| emissionImmunity | EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3 |
| antiIslandingStandard | See our website |
