MultiPlus 12/1200/50-16 120V VE.Bus
In stock
$ 573
In stock
The new style MultiPlus is set to replace the earlier MultiPlus Compact range. It is a powerful true sine wave inverter, a sophisticated battery charger that features adaptive charge technology and a high-speed AC transfer switch in a single compact enclosure.
Additional information
| Weight | 8,4 kg |
|---|---|
| Dimensions | 25 × 38 × 11 cm |
| batteryVoltageNominal | 12 V |
| powerControl | 1 |
| powerAssist | 1 |
| parallelOperation | 1 |
| threePhaseOperation | 1 |
| transferSwitchCurrentRating | 16 A |
| dCInputVoltageRange | [9.5, 17] VDC |
| aCOutputVoltage | 120 VAC |
| aCOutputFrequency | 60 Hz |
| contPowerVA25 | 1, 200 VA |
| contPowerW25 | 1, 000 W |
| contPowerW40 | 900 W |
| contPowerW65 | 600 W |
| peakPowerRating | 2, 400 W |
| maxEfficiency | 93 % |
| zeroLoadPower | 13 W |
| zeroLoadPowerSearch | 4 W |
| aCInputVoltageRange | [95, 140] VAC |
| aCInputFrequencyRange | [55, 65] Hz |
| chargeVoltageAbsorption | 14.4 VDC |
| chargeVoltageFloat | 13.8 VDC |
| chargeVoltageStorage | 13.2 VDC |
| chargeAlgorithm | Adaptive, 4-stage |
| maximumBatteryChargeCurrent | 50 A |
| temperatureSensor | Included |
| programmableRelay | AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC |
| protections | Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple |
| communicationPort | VE.Bus |
| remoteTerminal | On / Off / Charger only |
| dIPSwitchesProgramming | 1 |
| computerProgramming | 1 |
| internalDCFuseRating | 200 A |
| fanAssistCooling | 1 |
| maxHumidity | 95 % |
| aCConnectionTerminalType | G-ST18i plug |
| remoteTerminalType | Screw terminal two pole |
| relayTerminal | Screw terminal 3-pole |
| vebusTerminalType | One RJ45 terminal, RJ45-spliter ASS030065510 to expand to two ports |
| material | Steel chassis with ABS cover |
| colour | Blue (RAL 5012) |
| protectionCategory | IP21 |
| weight | 8.2 kg |
| height | 406 mm |
| width | 250 mm |
| depth | 100 mm |
| safety | EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1 |
| emissionImmunity | EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3 |
| automotiveDirective | ECE R10-4 |
