MultiPlus-II 24/3000/70-50 2x120V *If 0, order PMP242305132*
In stock
$ 1.334
In stock
The MultiPlus-II 2 x120V is the perfect one-box mobile solution for standard North American 50A 120/240VAC split-phase applications. Whether it is supplied from shore power or a generator, the MultiPlus-II 2x120V can accept and passthrough both lines of a 120/240V supply, with the capability to utilize the full 50A for charging and AC loads. When connecting to a single phase 120V supply, the L1 input of the MultiPlus-II 2x120V will accept incoming power for charging and passthrough, while combining the L1 and L2 outputs for single-phase 120V on each line.
The MultiPlus switches to inverter operation when no AC source is available. The inverter output is also 120V single phase. In inverter mode, the MultiPlus-II 2x120V internally connects both lines L1 and L2 together to provide 120VAC to loads on either output. Therefore, in all connection circumstances, both sides of a distribution panel will be supplied with 120V. However, 240VAC is only available when the MultiPlus is supplied by a split phase 120/240VAC source. This prevents heavy loads such as water heaters or 240V air conditioners from discharging the battery.
The MultiPlus-II 2x 120V has all of the expected features of our versatile inverter/charger range, including PowerControl, PowerAssist, Input Current Limit, two AC outputs, as well as parallel and 3ph configuration for larger capacity VE.Bus systems. Suitable for LiFePO4 batteries and a variety of other battery technologies.
Additional information
| Weight | 20,88 kg |
|---|---|
| Dimensions | 34,7 × 63,7 × 24,4 cm |
| batteryVoltageNominal | 24 V |
| powerControlAndAssist | 1 |
| transferSwitchCurrentRating | 50 A |
| maxAcInputCurrent | 50 A |
| dCInputVoltageRange | [19, 33] VDC |
| aCOutputVoltage | 120 VAC |
| aCOutputFrequency | 60 Hz |
| contPowerVA25 | 3, 000 VA |
| contPowerW25 | 2, 400 W |
| contPowerW40 | 2, 200 W |
| contPowerW65 | 1, 700 W |
| maxAppFeedinPower | 2, 500 VA |
| peakPowerRating | 5, 500 W |
| maxEfficiency | 94 % |
| zeroLoadPower | 11 W |
| zeroLoadPowerAES | 8 W |
| zeroLoadPowerSearch | 4 W |
| aCInputVoltageRangeSplit | [180, 280] VAC |
| aCInputVoltageRangeSingle | [90, 140] VAC |
| aCInputFrequencyRange | [45, 65] Hz |
| chargeVoltageAbsorption | 28.8 VDC |
| chargeVoltageFloat | 27.6 VDC |
| chargeVoltageStorage | 26.4 VDC |
| chargeAlgorithm | Adaptive, 4-stage |
| maximumBatteryChargeCurrent | 70 A |
| temperatureSensor | Included |
| AuxiliaryOutput | 1 |
| programmableRelay | AC rating: 120V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC |
| protections | Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple |
| communicationPort | VE.Bus |
| communicationPortGeneral | 1 |
| remoteTerminal | On / Off |
| computerProgramming | 1 |
| fanAssistCooling | 1 |
| maxHumidity | 95 % |
| batteryConnectionTerminalType | M8 bolts (two for positive and two for negative connection) |
| remoteTerminalType | Screw terminal two pole |
| relayTerminal | Screw terminal 3-pole |
| vebusTerminalType | Two RJ45 terminals |
| material | Steel |
| colour | Blue (RAL 5012) |
| protectionCategory | IP22 |
| weight | 22 kg |
| height | 578 mm |
| width | 275 mm |
| depth | 148 mm |
| safety | EN-IEC 60335-1, EN-IEC 60335-2-29 |
| emissionImmunity | EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3 |
