MultiPlus-II 48/3000/35-50 120V (UL 1741)
In stock
$ 1.375
In stock
The MultiPlus-II combines the functions of the MultiPlus and the MultiGrid.
It has all the features of the MultiPlus, plus an external current transformer option to implement PowerControl and PowerAssist and to optimize self-consumption with external current sensing (max. 32A).
It also has all the features of the MultiGrid with built-in anti-islanding and an increasingly long list of country approvals.
Note: for a short period of time this product was called MultiGrid-II.
Additional information
| Weight | 18,35 kg |
|---|---|
| Dimensions | 35 × 58 × 24 cm |
| batteryVoltageNominal | 48 V |
| powerControl | 1 |
| powerAssist | 1 |
| parallelOperation | 1 |
| threePhaseOperation | 1 |
| transferSwitchCurrentRating | 50 A |
| maxAcInputCurrent | 50 A |
| dCInputVoltageRange | [38, 66] VDC |
| aCOutputVoltage | 120 VAC |
| aCOutputFrequency | 60 Hz |
| contPowerVA25 | 3, 000 VA |
| contPowerW25 | 2, 400 W |
| contPowerW40 | 2, 200 W |
| contPowerW65 | 1, 700 W |
| peakPowerRating | 5, 500 W |
| maxEfficiency | 95 % |
| zeroLoadPower | 11 W |
| zeroLoadPowerAES | 7 W |
| zeroLoadPowerSearch | 2 W |
| aCInputVoltageRange | [90, 140] VAC |
| aCInputFrequencyRange | [45, 65] Hz |
| chargeVoltageAbsorption | 57.6 VDC |
| chargeVoltageFloat | 55.2 VDC |
| chargeVoltageStorage | 52.8 VDC |
| chargeAlgorithm | Adaptive, 4-stage |
| maximumBatteryChargeCurrent | 70 A |
| temperatureSensor | Included |
| AuxiliaryOutput | 1 |
| externalAcCurrentSensor | 100A (optional) |
| programmableRelay | AC rating: 120V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC |
| protections | Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple |
| communicationPort | VE.Bus |
| communicationPortGeneral | 1 |
| remoteTerminal | On / Off |
| computerProgramming | 1 |
| fanAssistCooling | 1 |
| maxHumidity | 95 % |
| batteryConnectionTerminalType | M8 bolts |
| remoteTerminalType | Screw terminal two pole |
| relayTerminal | Screw terminal 3-pole |
| vebusTerminalType | Two RJ45 terminals |
| material | Steel |
| colour | Blue (RAL 5012) |
| protectionCategory | IP22 |
| weight | 19 kg |
| height | 572 mm |
| width | 277 mm |
| depth | 147 mm |
| safety | CSA C22.2 107.1-16, EN-IEC 60335-1, EN-IEC 60335-2-29, UL 1741 |
| emissionImmunity | EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3 |
