Phoenix Inverter 12/250 230V VE.Direct SCHUKO

Name: Phoenix Inverter 12/250 230V VE.Direct SCHUKO
Brand: Victron
SKU: PIN121251200
Availability: InStock

In stock

$ 133

In stock

Inverters allow you to power domestic equipment - requiring 230V/120V AC - using 'leisure' or 'automotive' batteries rated at 12V, 24V or 48V DC.

Additional information

Weight	2,6 kg
Dimensions	21 × 30 × 15 cm
batteryVoltageNominal	12 V
contPowerVA25	250 VA
contPowerW25	200 W
contPowerW40	175 W
peakPowerRating	400 W
aCOutputVoltage	230 V
frequency	50 Hz
dCInputVoltageRange	[9.2, 17] V
dCLowShutDown	9.3 V
dCLowRestartAlarm	10.9 V
dynamicLowDCShutdown	1
maxEfficiency	87 %
zeroLoadPower	4.2 W
zeroLoadPowerEcoMode	0.8 W
ecoModeRetryInterval	2.5 s
remoteOnOffTerminal	1
communicationPort	VE.Direct
fullyProgramable	1
protections	Excessive DC ripple,High battery voltage,Low battery voltage,Output short-circuit,Over temperature,Overcurrent,Overvoltage
maxHumidity	95 %
powerDeration	1.25 %
aCOutletSocket	Schuko (CEE 7/4)
remoteTerminal	Screw terminal two pole
colour	Blue (RAL 5012)
material	Steel chassis and plastic cover
protectionCategory	IP21
weight	2.4 kg
height	86 mm
width	165 mm
depth	260 mm
safety	EN-IEC 60335-1,EN-IEC 62109-1
eMC	EN 55014-1,EN 55014-2,EN-IEC 61000-6-1, EN-IEC 61000-6-2,EN-IEC 61000-6-3
automotiveDirective	ECE R10-4
