Phoenix Inverter 24/250 120V VE.Direct NEMA GFCI (UL 458)
In stock
$ 111
In stock
Inverters allow you to power domestic equipment - requiring 230V/120V AC - using 'leisure' or 'automotive' batteries rated at 12V, 24V or 48V DC.
Additional information
| Weight | 2,52 kg |
|---|---|
| Dimensions | 21 × 30 × 15 cm |
| batteryVoltageNominal | 24 V |
| contPowerVA25 | 250 VA |
| contPowerW25 | 200 W |
| contPowerW40 | 175 W |
| peakPowerRating | 400 W |
| aCOutputVoltage | 120 V |
| frequency | 60 Hz |
| dCInputVoltageRange | [18.4, 34] V |
| dCLowShutDown | 18.6 V |
| dCLowRestartAlarm | 21.8 V |
| dynamicLowDCShutdown | 1 |
| batteryChargedDetectionVoltage | 28 V |
| maxEfficiency | 88 % |
| zeroLoadPower | 5.2 W |
| zeroLoadPowerEcoMode | 1.3 W |
| ecoModeRetryInterval | 2.5 s |
| ecoModeStopStartPowerSetting | Adjustable |
| remoteOnOffTerminal | 1 |
| communicationPort | VE.Direct |
| fullyProgramable | 1 |
| protections | Excessive DC ripple, High battery voltage, Low battery voltage, Output short-circuit, Over temperature, Overload |
| maxHumidity | 95 % |
| powerDeration | 1.25 % |
| aCOutletSocket | Nema 5-15R, GFCI |
| remoteTerminal | Screw terminal two pole |
| colour | Blue (RAL 5012) |
| material | Steel chassis and plastic cover |
| protectionCategory | IP21 |
| weight | 2.4 kg |
| height | 85 mm |
| width | 182 mm |
| depth | 255 mm |
| safety | EN-IEC 60335-1, EN-IEC 62109-1, UL 458 |
| eMC | EN 55014-1, EN 55014-2, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3 |
| automotiveDirective | ECE R10-4 |
