Name: Cyrix-Li-charge 12/24V-120A intelligent charge relay
Brand: Victron
SKU: CYR010120430
Availability: BackOrder

Cyrix-Li-charge 12/24V-120A intelligent charge relay

$85.00

AvailableShips next business day

Congratulations! You got free shipping 🎉

Extra Features

Premium Quality
Secure Payments
Satisfaction Guarantee
Worldwide Shipping
Money Back Guarantee

Guaranteed Safe Checkout

The Cyrix Battery Combiner is a microprocessor controlled heavy duty relay that automatically connects batteries in parallel when one of them has reached a pre-set voltage (indicating that the battery is being charged), and disconnects when the voltage decreases below float level (indicating that one or more batteries are being discharged). Cyrix Battery Combiners are an excellent replacement for diode isolators. The main feature is that there is virtually no voltage loss so that the output voltage of alternators or battery chargers does not need to be increased.

Weight	0.3 lbs
Dimensions	2.6 × 3 × 2 in
Dimensions (L x W x H mm)	65 x 75 x 50 mm
Nominal Battery Voltage	12V or 24V
Continuous Current1224	120 A
Connect Profiles	See our website
Control Input	The Cyrix engages when the control input is high (appr. Battery voltage) The Cyrix disengages when the control input is left free floating or pulled low
Current Consumption Open	4 mA
Protection Category	IP54
Weight	0.11 kg
Height	64 mm
Width	64 mm
Depth	80 mm
