Name: Battery Monitor BMV-712 Smart
Brand: Victron
SKU: BAM030712000
Availability: BackOrder

With Bluetooth built-in, the BMV Smart is ready for the Internet of Things (IoT) era. With Bluetooth being implemented in most other Victron Energy products, wireless communication between products will simplify system installation and enhance performance.

To read more about the full BMV range & accessories, see this blog.

Weight	1.4 lbs
Dimensions	8.3 × 8.3 × 2.6 in
Dimensions (L x W x H mm)	210 x 210 x 65 mm
Supply Voltage Range	[6.5, 70] VDC
Current Rating	500 A
Battery Capacity Measurement Range	[1, 9,999] Ah
Current Draw	1 mA
Input Voltage Measurement Range Auxiliary Battery	[6.5, 70] VDC
Aux Input Fo Auxiliary Battery Voltage	1
Temperature Sensor	Optional (ASS000100000)
Communication Port	VE.Direct
Bluetooth	1
Programmable Relay	Bistable relay 60V / 1A , normally open (function can be inverted)
Display	1
Visual Alarm On Device	1
Audible Alarm On Device	1
Current Measurement Resolution	0.01 A
Voltage Measurement Resolution	0.01 V
Capacity Measurement Resolution	0.1 Ah
State Of Charge Measurement Resolution	0.1 %
Time To Go Measurement Resolution	1 min
Measurement Accuracy	0.4 %
Current Measurement Accuracy	0.4 %
Voltage Measurement Accuracy	0.3 %
Positive Cable	1.5m cable with 1A fuse
Aux Cable	1.5m cable with 1A fuse
Shunt Connection Terminals	M10 bolts
Colour	Grey
Protection Category	IP55 (not for outdoor use)
Front Diameter	63 mm
Front Bezel	69 x 69mm
Body Diameter	52 mm
Body Depth	31 mm
Shunt	500A / 50mV
Safety	EN 60335-1
Emisison Immunity	EN 55014-1,EN 55014-2
Automotive Directive	ECE R10-4,EN 50498
Data Stored	Battery voltage,Battery current,Battery temperature,Battery state of charge percentage,Battery midpoint deviation,Starter battery voltage
Data Retention Period	46 d
Display Shunt Cable	10 metre 6-core UTP with RJ12 connectors
Installation	Flush mount
